High-Tem... moreInconel Seamless Pipe China Manufacturer
INCONEL 625 | Deep Sea Pressure Master
Solution-strengthened Ni-Cr pipes rated for 10,000m depth. Yield strength >700 MPa at 4K temperature. Subsea Christmas tree components approved.
Inconel Seamless Pipe Specification
Technical Specifications
Yield Strength 1100 MPa (Aged)
Fatigue Limit 825 MPa @10⁷ cycles
Heat Treatment 720°C×8h + 620°C×8h
NDT Level UT Level B per AMS 2631
Features of Inconel Seamless Pipe
Inconel 625 Seamless Tubes
High-Temperature Chemistry:
Fe/Ni-based alloy strengthened by niobium-tantalum complex (Nb+Ta: 3.15-4.15%). Aluminum/titanium limitation (<0.40%) prevents gamma-prime formation. Chromium (20-23%) develops self-repairing Cr₂O₃ layers at extreme temperatures.
Mechanical Performance Profile:
Creep Rupture: 180 MPa @815°C for 10,000h
Cyclic Oxidation: <0.05 mg/cm² mass loss @980°C (ASTM G54)
Cryogenic Toughness: 120J Charpy impact @-196°C
Fatigue Strength: 550 MPa @10⁷ cycles (R=0.1)
Aerospace Manufacturing:
Cold pilgering achieves wall thickness tolerances of ±5%. Solution annealing at 1150°C under argon cover gas. Continuous eddy current testing detects flaws >0.125mm deep per AMS 2631B.
Demanding Use Cases:
Rocket engine combustion chambers (NASA-STD-5008)
Nuclear fuel cladding in PWR reactors (ASME Sec III)
Deep-sea MPD (managed pressure drilling) systems
Plasma etching chambers in semiconductor fabs
Aerospace Approvals:
AMS 5599 • ESA PSS-01-702 • NADCAP AC7114/1
#inconel #601 #seamless #pipe
